Fiber Glass Conduit Rod

Share to:
Payment Type: L/C,T/T,D/P,Money Gram,Western Union
Terms of Trade: FOB,CFR,CIF,EXW,FCA,CPT,CIP
Min. Order: 1
Delivery Time: 5
Basic Info
Model No.:HK-005
Additional Info
Packaging: Ordinary/box/dag
Productivity: 10000000
Brand: HK
Transportation: Ocean,Land,Air
Place of Origin: China
Supply Ability: 100sets/day
Certificate: ISO
HS Code: 39269090
Port: Tianjin Port,Qingdao Port,Shanghai Port
Product Description

Fiber Glass Conduit Rod




FRP Duct Rodder is an ideal tool for underground jobs such as pulling cables and lines through conduits, tubes, pipes or ducts. For its high tensile strength, wear-resistant surface and elastic body, it is widely used in the fields of telecommunication, electric power, water conservancy, etc.

Fiberglass Duct rodder, also called conduit rodder, duct snake, is a fiberglass based rod material used for soft wire, strip and other materials conveying in the duct, conduit or tubes.



Material:

  • Internal wire: copper or steel.
  • Inner rod: fiberglass.
  • Exterior coating: UV resistance polyethylene.
  • Wheel: rubber, steel.
  • Drawing head: copper.
  • Frame: steel.

Frame finish: powder coated, zinc plated.

Specification:

  • Rod diameter: 4mm - 16mm.
  • Length of fiberglass rod: 30m - 500m.
  • Working temperature: -40°C to + 80°C (-40°F to 176°F).
  • Minimum bend radius: 4" (That is for 4mm rod diameter, other rods with larger diameter have larger bend radius).
  • Max pulling strength: 4.5T (For rod diameter 16mm, other rods with smaller diameter have less pulling strength).
  • Frame size: 160mm × 450mm × 500mm, 170mm × 600mm × 750mm, etc. (maximum size: 550mm × 1500mm × 1600mm).
  • Wheel: pneumatic/iron tyre or no wheel.
  • Fiberglass rod color: yellow, blue, white, red, black.
  • Package: plastic wrap and then into carton.
  • Operation instruction: see the Technology page.

Features:

  • Light weight, high tensile strength.
  • Polyethylene coating for good electric insulativity, smooth surface, resistance to acid and corrosion.
  • Elastic body for easy passing through narrow pipes and bending conduits.
  • Copper wire inside for tracing if needed.
  • Good friction and heat resistance allow the rod to travel longer distance in the conduits and to be operated in harsh environment.
  • Meter marks on the protective layer of the rod for measuring distance, printed by professional printing machine.
  • Waterproof and anti-ultraviolet for durable use.
  • Hand operated brake for controlling payout of the pulling rod. The rotating and stopping of the rod can be easily controlled by the brake.
  • Some frames are double-barreled reinforcement design for a more sturdy structure.
  • Small bending radius allows the rod itself passing through tight bends in the ducts.
  • Accessory or repair kit is available attached to the frame for greater versatility and easier ducting.


Note: we offer various sizes and colors for any specific requirement as customers' demand.


Fiber Glass Conduit Rod


Traceable Duct Rodder

Metallic Duct Rodder

Stanlay Traceable Maxi Duct Rodder


FRP Fiber Glass Push PullerFRP Duct Rodder


FRP Duct Rodder also named Fiberglass Duct Rodder , Cable Roller , Push Pull Rod , Electric Duct Rodder , FRP Snake Duct Rodder ...



1, Why you will choose us ?

More than 10 years of experience in production and sales ; Excellent production quality control and sales team .


2,How about our price of FRP Duct Rodder ?

Advantage production technology ; Skilled operation mechanic ; Cost advantage with mass production ; Perfect management .


3,How about our service ?

Prompt reply within 24 hours ; Production and delivery on time ; Professional solutions and operations .






Looking for ideal Traceable Duct Rodder Manufacturer & supplier ? We have a wide selection at great prices to help you get creative. All the Metallic Duct Rodder are quality guaranteed. We are China Origin Factory of Fiber Glass Conduit Rod. If you have any question, please feel free to contact us.
